TOOLS
10 pc. TOOL SET
Atool for all applications for trimmer adjustments. Set
Includes square tips, hex tips, different size screwdriver
blades and recessed blades. Manufactured with tough cel-
con material.
No. 63-910
10 PIECE ELECTRONIC
COMBINATION WRENCH SET
This fine quality set of 10
combination wrenches is
excellent for electronic repair
and service. The size and
thickness are especially suit-
ed for technician needs.
The wrenches are the follow-
ing sizes: 5/32, 3/16, 1/4,
7/32, 15/64, 5/16, 9/32,
3/8, 11/32, and 7/16. All
are hot forged and chrome
plated.
No. 63-608
ALIGNMENT TOOLS
MINIATURE POTENTIOMETER, TRIMPOT TOOL
One end is a recessed blade for non-slip adjustment of miniature
potentiometers that have a protruding adjustment screw. The other
end has a protruding metal blade for pots with flush screw-slot
adjustment. Small steel tips have negligible flux-effect: body is
molded of anti-static plastic. Replaces types 8608, AS8608.
No. 63-8608
SQUARE and HEX ALIGNMENT TOOL
Square: .060 Hex: 0.10
A double-ended, anti-static alignment tool for ferrite core trans-
formers. One end is a square .060 Tip with an additional protrud-
ing flat (.024 thick) blade. The other end is a 0.10 hex with a pro-
truding (.039 thick) blade. Replaces types 9440 and AS9440..
No. 63-9440
STEEL TIP DUAL ALIGNMENT TOOL
Recessed steel tip one end, protruding steel tip on the other. Tool
shaft dia. 7/32 (5.5mm). The recessed tip fits a no.6 slotted shaft
common to many I.F. transformers. The protruding tip is .130 wide
and protrudes .190. Molded of anti-static material. Replaces types
8276 and AS8276.
No. 63-8276
DOUBLE HEX ALIGNMENT TOOL
Abroad usage tool with stepped .078 hex and 0.10 hex on one
end, preceded by a fine .020 x .065 flat blade. The opposite end
is a 0.10 hex preceded by a .030 x .10 flat blade. Overall length
is 7-9/16, molded of durable Nylon.
No. 63-9297
LONG REACH ALIGNER, WITH HANDLE
Aplastic alignment tool with a 0.02 x .080 steel tip. Length of
shaft from tip to handle is 5-3/4. overall tool length is 7-7/8. Shaft
is somewhat flexible for tight spots; handle provides better grip
than regular alignment tools.
No. 63-5001
DOUBLE 078 HEX ALIGNER
HEX: .078
A Nylon tool .078 hex on both ends; one end undercut for reach-
ing through to a bottom slug, the other with a stop to prevent over-
reaching. Replaces type 9300.
No. 63-9300
163
