CRIMPING TOOL
for
“D”
SUBMINIATURE CONNECTORS
CRIMPING TOOL
for
“F” CONNECTORS
PROFESSIONAL HEX CRIMP TOOL
Perfect for CATV, MATV and TVRO installations, when heavy duty crimping is required.
It’s light enough to fit conveniently in an installers belt. Features cushion plastic handles for com-
fortable gripping. 9” overall length.
Works for all Philmore crimp-on connectors for stated wire type: ‘F’, BNC, TNC, UHF, Mini UHF,
SMA.
No. WS25
- Crimps RG59/U, RG6/U
No. WS27
- Crimps RG58/U, RG59/U
and Pin Crimping Position
No. WS29
- Crimps Philmore Pro-Crimp
“F” connectors, RG11/U
Hand held tool crimps D-Sub pins (male and
female) with a single squeeze on the contact
material. Has built-in wire cutter.
PVC handle allows crimping in comfort.
No. WS26
For a tight, permanent crimp, this ferrule tool
does the proper job every time. Two slots are
provided for RG59/U and RG58/U coaxial
cable.
No. WS17
PROFESSIONAL D-SUB CONTACT
RATCHET CRIMPING TOOL
• Precision
• High Quality
• Durable
No. YAC4
D-Sub Contact
Crimping Tool
• 18-22 AWG, 24-30 AWG
• Six section pressure adjustment
• For female and male D-subminiature contacts
INTERCHANGEABLE CRIMP DIES
for Nos. WS28, WS34, WS36
• Full cycle ratchet mechanism with quick
release safety lock
• High carbon steel ratchet frame
• PE insulation grip handle for comfort
and maximum crimping force
• Interchangeable dies for F, BNC, TNC, N,
Teflon, Thinnet-PVC / Teflon and Fiber-Optic
connectors
Professional Ratchet Crimp Tool
w/ Interchangeable Dies
No. WS28
- (RG58/U, RG59/U and 1/16” pin)
No. WS34
- For Insulated Terminals:
(22-18 AWG, 16-14 AWG and 12-10 AWG)
No. WS36
- (RG58/U, RG59/U and RG6/U)
T-TOOL
Easy assembly of screw-on or
regular “F”connectors. Great
finger saver for assembly of
twist-on or regular crimp-on “F”
connectors. Just assemble “F”
connector by threading on to
T-TOOL, then assemble con-
nector.
No. WS70
ECONOMY HEX CRIMPING TOOL
For a tight and permanent crimp. Designed for coaxial fittings on
RG59/U, RG62/U and RG6/U. PE insulation grip handle for com-
fort and maximum crimping force. Made of tempered steel. 8”
long.
No. 12-170
IDC CRIMPING TOOL
No. HT214R
- Replacement Crimping Block
This all-steel construction tool with cushioned han-
dle grips provides good short run production capa-
bilities for all insulation displacement connector
assembling. Works for D-Sub and Centronics.
No. HT214
Part No.
Dies Only
No. WS74
No. WS78
No. WS80
No. WS82
No. WS84
No. WS88
Formerly WS28D1
.319”
.255”
.178”
.256”
.256”
.213”
.151”
.255”
.213”
.213”
.137”
.128”
.213”
.100”
.078”
.187”
.068”
.068”
.069”
.068”
.068”
.043”
.042”
Coded: Red 22-18 Blue 16-14
Yellow 12-10
For Crimping RG Type Cable
59, 62, 140, 210, BELDEN 8279.
55, 58, 141, 142, 223, 303, 400, Fiber Optic
6, 59, 62, 140,210, BELDEN 8279
55, 58, 141, 142, 223, 303, 400, Fiber Optic.
59, 62, 8X, 140, 210, BELDEN 8279.
55, 58, 141, 142, 223, 303, 400, Fiber Optic
122, 174, 179, 180, 187, 188, 195, Fiber Optic
178, 316, BELDEN 8218.
55, 58, 59, 62, 140, 141, 142, 210, 223.
174, 303, 400, Fiber Optic, BELDEN 8279.
Insulated Terminals 10-22 ga.
