TEST ACCESSORIES
JUMPER CABLE SETS
10-piece sets
Color coded lead wires with insulated alligator clips on each end. Each
set includes ten leads, two each of five different colors. Indispensable
for testing service, during circuit design etc.. We suggest the Techs set
to professional users, or the
No. SA44
below.
Colors:
Black, Green, Red,
White and Yellow
Test Lead Wire
Perfect for making test
leads. This is same quality
wire as used on Philmore
Nos. 466 and 467 Test
Leads. Wire is 18 Gauge
tinned and stranded. O.D.
of cable is .135. Lead wire
is very flexible and guaran-
tees no kinked leads.
Available in RED and
BLACK.
No. 472
- 25 ft., black
No. 476
- 25 ft., red
No. 474
- 100 ft., black
No. 478
- 100 ft., red
No. SA10
- Economy set, standard
(3 strand wire) 14 long
No. SA22
- Techs Jumper Cable Set,
(12 strand wire), 22 long
IC TEST
LEAD SET
No. 500
5 color-coded, 16 test leads with miniature
hook-on prods at both ends. A must for
technicians and experimenters who want
temporary interconnects with out danger of
shorting.
Colors: Red, black, yellow, green, white
RG58/U CABLE ASSEMBLIES
No. CA900
BNC male connector on both ends of 3-foot
RG58/U cable
No. CA898
6 RG58/U, BNC Male to UHF Male.
No. CA901
BNC male connector to two color-coded alligator
clips attached to a 3-ft. RG58/U cable.
No. CA890
3 RG58/U, UHF Male to UHF Male.
No. CA892
6 RG58/U, UHF Male to UHF Male.
HEAVY DUTY
JUMPER CABLE SETS
For serious user in the lab or test bench, sets
include five tough Jumper Cable, of five different
colors, with insulated alligator clips one each end.
20 strand wire and flexible insulation is used for
long life.
Colors:
Black, Green, Red, White and Yellow
No.SA44
-
Set of five, 22 long leads
No.SA45
- Set of five, 36 long leads
Plastic test prod handles, 4 long, 3/8 diameter, with prods 1 long. Red and Black. Equipped with 48
kinkless plastic-covered leads .135 O.D. Available with either insulated banana plugs or phone tips at
other end, to fit standard American jacks.
The most useful test leads yet devised. Use them in the conventional manner or adapt them
to individual requirements.
Tiny, sturdy, push-to -clip prods can be firmly attached to hard-to-reach components in
chassis-whether large or small terminals. Clip-onto-component feature enables you to test
parts for long periods without actually handling the test leads. Hands are free for other work.
Each prod is connected with solderless, kinkless wire terminating in an insulated banana
plug
Aremovable, nickel-plated phone tip (supplied) fits over the banana plug allowing the indi-
vidual the option of using meters with either banana or phone tip jacks.
Overall leads length is 36 inches.
ALL-PURPOSE
TEST LEAD SET
No.470
Two 42 flexible, vinyl-covered test leads, heavily insulated to prevent high voltage
breakdown and cut-through. 80 -strand copper conductors eliminate wire fatigue and
assure long life.
Equipped with adaptor accessories most often used by servicemen, this kit can per-
form virtually every test requirement. Each lead is attached to a 4-3/4 probe (1-red,
1-black). Banana plugs on each end have nickel-plated phosphor bronze springs to
maintain rigid contact through many thousands of insertions.
Heavy plated BRASS Adaptors-Color-coded Spade Lugs*
-large enough for lab.
instruments (up to 1/4 dia. center post).
Test prod phone tips
(0.180 dia.)
Strong spring action alligator clips.
NP phone tips.
-not insulated.
Each insulated adaptor completely covers banana plugs to eliminate accidental con-
tact, avoiding shorts.
DELUXE UNIVERSAL
SOLDERLESS TEST
LEAD SET
No.SA15
TEST LEADS
No. 466
Phone Tips
No. 467
Banana Plugs
Two unbreakable high dielectric strength prods, black and red
