HOME / OFFICE ACCESSORIES
42
DOUBLE COIL BUZZER
No. TW15
- Pair to Display Box
No. TW15E
- Single to Display Box
SPECIFICATIONS:
Power Source:
115V 120V
Frequency:
Channel A 200KHz, Channel B 230 KHz; or adjusted to cus-
tomer’s specs
Modulation:
FM
Power Consumption:
3W
Featuring the latest in FM and Phased-Locked-Loop circuitry for crystal-
clear communication and maintenance-free operation. The system allows
three-station operation and can be expanded with add-on units. Absolutely
no installation is required; just plug into any AC outlet and use. The system
is ideally suited for private homes (as a remote, audio “babysitter”), offices,
factories, restaurants, hospitals, stores and schools.
FEATURES:
• Wireless - absolutely no installation required. Just plug into any AC
outlet and talk
• FM PLL (Phased-Locked-Loop) circuitry-gives you excellent and
noise-free conversation
• 2-channel selector-for use up to 4 stations operation
• Built-in “beep” call-for alerting other station
• Built-in squelch control-automatically eliminates fluorescent light
static, appliance motor noise, dimmer switch buzzing, etc.
• Built-in lock button-for continuous talking or baby-sitter monitoring
• Attractive styling makes it suitable for any decor
Automatic voice activation puts the intercom in the transmit mode
when you start talking. Stop talking and it automatically switches to
the receiver mode. Allows”hands free” operation while talking. If
you prefer manual operation, touch the “call” or “talk” SENSOR
SWITCH. Revert back to “automatic” with a single touch. A built-in
squelch system automatically eliminates electrical noises to trans-
mit crisp, clear sound.
No installation required - plug into any 110-120V AC outlet, turn set
on and talk! Apleasing “BEEP” sound alerts listener at the other
end. Buy them individually or in pairs, and add as many as desired.
SPECIFICATIONS:
CIRCUIT:
FM, phase-locked-loop
CHANNELS:
3
AUDIO POWER:
350mW
SIZE (Per Unit):
7”W x 4-3/4” x 2”H
This buzzer is ideal sounding
device for use with No. PE31
(above). Unit is connected to 12 V
output terminals on back of No.
PE31.
3-12 Volt DC
6-12 Volt AC
No. PE296
PHOTO-ELECTRIC
INFRARED RELAY
SYSTEM
2-CHANNEL FM WIRELESS INTERCOM
VOICE-ACTIVATED FM INTERCOM for
AUTOMATIC TWO-WAY CONVERSATIONS
OVER THREE CHANNELS
No. TW20
- Pair to a display box
No. TW20E
- Single to a display box
NORMAL - Power on when beam is
broken
REVERSE - Power off when beam is
broken
No bulbs to replace - it doesn’t use any.
Long life LED provides the pulsed
infrared beam.
Supplied with universal mounting brack-
ets to allow installation on walls, floors,
ceiling, flush mount and high efficiency
reflector. A built-in LED monitor lamp
denotes perfect alignment between the
unit and the reflector furnished.
No. PE31
SPECIFICATIONS:
Power Requirement:
Standby Power
Consumption:
Usable Range:
Reaction Time :
Release Time:
AC Switched Load:
DC Output:
Dry Contact Capacity:
Maximum Angular
Reflector Error:
Operating Temperature
Range:
Light Source:
Detector:
Reflector:
Fuse:
Dimensions:
Weight:
120 Volts AC, 50/60 Hz
10 Watts
2-1/2 ft. min to 50 ft. Max.
Less than 50 millisecond
Approx. 5 seconds in “INTER-
MITTENT” mode
120 Volts AC, 3 amps max.
(noninductive load)
12 Volts DC, 1 amp max. (12
ohm min load)
30 Volts DC, 3 amps, or 120
Volts AC, 3 amps
+ 10.
15.F (-10.C) to 105.F (40.C)
Pulse modulated infrared
Light Emitting Diode
Infrared sensitive photodiodes
High-efficiency, multi-faced
plastic 2-3/8” by 4-3/4”
1amp. AGC (3AG)
4-3/4” (120mm) x 5-7/8”
(150mm) x 6” (157mm)
2.8 lbs (1.3kg)
Invisible pulse beam effective
up to 50 feet--not affected by
outside lighting changes
Unlike most other one-piece relay systems,
this unit is capable of:
1. Tying in directly to any burglar alarm
system.
2. Operating 12 volt DC devices (such as
sirens, bells, counters) up to 1 amp
current.
3. Operating 120 volt AC devices drawing
up to 3 amps.
Six modes of operation are ready selected by
slide switches on the rear panel:
1. LOCK - Stays on until reset.
2. INSTANT - Actuates only when beam is
intercepted.
3. INTERMITTENT - Actuates for five
seconds after beam is broken.
PLUS NORMAL and REVERSE on any of the
above:
